- Explosion-Proof Engineering Flameproof motor and electrical components with a specially rated explosion-proof power supply, designed to eliminate ignition risk in hazardous gas atmospheres.
- 3,000 kg Rated Load Capacity Handles heavy industrial pallets and drums at a 600 mm load center with electromagnetic drive braking and 0.84 kW lift motor.
- Pedestrian Operation via Handle-Rod Walk-behind ergonomic interface suited to aisle and staging maneuvers in chemical plants, pharmaceutical facilities, and hazardous industrial areas.
- Optional Explosion-Proof Weighing System High-precision explosion-proof sensors with junction box, dedicated weighing meter, and optional wireless (Bluetooth/Wi-Fi) transmission for material traceability.
- Stainless-Steel Fork Cladding Option Corrosion-resistant fork surfaces for durability in chemical, food, or pharmaceutical environments with aggressive materials or cleaning regimes.
- Custom Fork Dimensions Non-standard fork sizing available to accommodate specialist pallets, racking systems, or process-specific material flow constraints.
Descrizione
The Topsky LT-3.0T is a pedestrian-operated explosion-proof electric pallet truck rated for a 3,000 kg load capacity at a 600 mm load center, built for material handling in industrial zones where combustible gas atmospheres may be present. Designed and produced by Beijing Topsky Century Holding Co., Ltd., the LT-3.0T applies flameproof and explosion-protected engineering to its motor and electrical systems, with a specially rated explosion-proof power supply, to minimise ignition risk from electrical arcing, sparks, and surface temperature exceedances. At 694 mm wide and weighing 460 kg including battery, it is sized for standard aisle widths while delivering full-load walking speed of 4.5 km/h and empty speed of 5 km/h with polyurethane tyres for smooth, low-noise (70 dB(A)) operation.
The LT-3.0T operates through a handle-rod interface, making it well suited to staging and material movement tasks in petroleum processing, chemical manufacturing, pharmaceutical production, textile facilities, and food manufacturing plants classified for hazardous area use. Beyond the base configuration, Topsky offers an optional explosion-proof weighing system using high-precision explosion-proof sensors, an explosion-proof junction box, and a dedicated weighing meter with wireless signal capability, as well as stainless-steel fork cladding for corrosion resistance and custom fork dimensions to accommodate non-standard pallets, racks, or process constraints. These options position the LT-3.0T as a compliance-ready platform for sites where material traceability, zone-based equipment certification, and corrosion control are operational requirements alongside basic pallet-handling capability.
Caratteristiche
Specifiche
| Brand | Topsky |
|---|---|
| Model | LT-3.0T |
| Power Type | Electric (battery-powered) |
| Operation Type | Walking / Pedestrian |
| Rated Load Capacity | 3,000 kg |
| Load Center Distance | 600 mm |
| Overall Width | 694 mm |
| Self-Weight (incl. battery) | 460 kg |
| Walking Speed (full load) | 4.5 km/h |
| Walking Speed (empty) | 5 km/h |
| Drive Motor Rated Power | 0.75 kW |
| Lift Motor Rated Power | 0.84 kW |
| Drive Brake Type | Electromagnetic |
| Tyre Type | Polyurethane |
| Noise Level | 70 dB(A) |
| Fork Lowered Height | 85 mm |
| Maximum Fork Lift Height | 115 mm (standard) |
Settori industriali
Domande frequenti
The LT-3.0T is a pedestrian-operated explosion-proof electric pallet truck with a 3,000 kg rated load capacity, designed for material handling — including loading, unloading, stacking, and staging — in industrial facilities where explosive gas atmospheres may be present, such as petroleum refineries, chemical plants, pharmaceutical manufacturing sites, and food processing facilities.
The LT-3.0T applies flameproof and explosion-protected design to its motor and electrical components, with a specially rated explosion-proof power supply. These measures are intended to minimise ignition sources such as electrical arcing, sparks, and excessive surface temperatures in classified hazardous areas where combustible gas mixtures may occur.
The LT-3.0T is designed for use in petroleum processing, chemical manufacturing, pharmaceutical production, textile facilities, food manufacturing, and national defence-related industrial operations — specifically in areas classified for hazardous gas atmospheres.
Robotix Market ships the LT-3.0T to customers worldwide. The product is covered by the manufacturer's warranty provided by Topsky. Robotix Market does not provide on-site installation or service.
Contact Robotix Market through the product page or our enquiry form. We will provide pricing, available configurations (including optional weighing systems and stainless-steel fork cladding), shipping terms, and lead times based on your operational requirements.
